Fly Ash Gypsum Powder
The strength of fly ash mixture often needs to be enhanced for its better utilization in geotechnical and environmental applications. Many fly ashes often improve their strength with lime but may not meet the requirements. Gypsum, which reduces the lime leachability, further improves the strength. An attempt is made in this paper to study the effect of gypsum on the strength development of two Class F fly ashes with different lime contents after curing them for different periods. The sustainability of improved strength has been examined after soaking the cured specimens in water and with different leachates containing heavy-metal ions. The strength of both the fly ashes investigated improved markedly up to a particular amount of the lime content, which can be taken as optimum lime content, and thereafter the improvement is gradual. The improvement in strength at higher lime contents continues for a longer period (even up to 180 days). Gypsum accelerates the gain in strength for lime-stabilized fly ashes, particularly in the initial curing periods at about optimum lime content. At high lime contents gypsum attributes very high strength after curing for long periods mainly due to the alteration of fly ash lime reaction compounds. Gypsum not only improves the reduction in the loss of strength due to soaking even at low curing periods but also improves the durability of stabilized fly ashes due to repeated cycles of wetting and drying.
Fly ash, Hydrated lime, Quarry dust and gypsum are manually fed into a pan mixer where water is added in the required proportion for intimate mixing. The proportion of the raw material is generally in the ratio depending upon the quality of raw materials. After mixing, the mixture is shifted to the hydraulic Brick Making machines. The bricks are carried on wooden pellets to the open area where they are dried and water cured for 14 days. The bricks are tested and sorted before dispatch.
Method No. 1:-
| Material | Mass |
|---|---|
| Fly ash | 60% |
| Sand/Stone dust | 30% |
| Ordinary Portland Cement/(Lime+Gypsum) | 10% |
| Total formula of material | 100% |
Method No. 2:-
| RAW MATERIAL NAME | NORMAL METHOD | PROFITABLE METHOD |
|---|---|---|
| Fly ash | 62% | 20% |
| Lime | 8% | 15% |
| Gypsum | 5% | 5% |
| Sand or Quarry Dus | 25% | 60% |
